Σε Άριστη Κατάσταση , στην συσκευασία τους.
Audioengine 5+
Τιμή 380 Ευρώ. Τηλ.6942980705
Audioengine 5+
150W peak power total (50W RMS / 75W peak per channel), AES
Inputs
3.5mm stereo mini-jack, RCA L/R
Outputs
RCA variable line-out, USB (power/charge)
Input Voltages
115/240V, 50/60Hz manually switchable
Amplifier Type
Dual Class AB monolithic
Drivers
5" Kevlar woofers, 3/4" silk dome tweeters
SNR
>95dB (typical A-weighted)
THD+N
<0.05% at all power settings
Crosstalk
-50dB
Frequency response
50Hz-22kHz ±1.5dB
Input impedance
10K ohms unbalanced
Protection
Output current limiting, thermal over-temperature, power on/off transient protection, replaceable external main fuse
Dimensions (each speaker HWD)
Left - 10.75" (27cm) x 7" (18cm) x 9" (23cm)
Right - 10.75" (27cm) x 7" (18cm) x 7.75" (20cm)
Weight (LEFT speaker)
15.4 lbs (7 kg)
Weight (RIGHT speaker)
9.6 lbs (4.4 kg)
Shipping weight
31 lbs (14 kg)
Shipping box dims
15" (38cm) x 22" (56cm) x 11.5" (29cm)
Finish options
Satin Black
Hi-Gloss White
13mm thick MDF cabinets
3/4" silk dome tweeters with neodymium magnets
5" Kevlar woofers with advanced voice coils
Torroidal power transformer
D1 24-bit DAC
DAC type
Dual Mode USB and Optical (SPDIF)
Inputs
USB/Optical (SPDIF)
Outputs
RCA stereo/3.5mm headphone
D/A converter
AKM4396
Optical receiver
CS8416
USB controller
TI1020B
USB device class
Type 1.1 or above
Full-scale output
2.0V RMS
Output impedance
10 ohms
Power source
USB 5V
Power requirements
5V DC, 200mA
USB power filtering
2-stage redundant regulation
SNR
(DC to 20 kHz) >110dB
THD+N
(1kHz FS 96kS/s) <0.0025%
Crosstalkb
-85db
USB transfer mode
Asynchronous (dual clock)
Frequency response
10Hz - 25KHz (+/- 0.5dB)
Input bit depth
16 bit, 24 bit
Input sample rate (USB)
32kHz-96kHz - native playback
188.2kHz, 192kHz - re-sampled to 96kHz for playback
Input sample rate (optical)
32kHz-192kHz - native playback
Product dimensions
3.5x4x1"
Shipping weight
1.0lbs (0.5kg)
Inputs
3.5mm stereo mini-jack, RCA L/R
Outputs
RCA variable line-out, USB (power/charge)
Input Voltages
115/240V, 50/60Hz manually switchable
Amplifier Type
Dual Class AB monolithic
Drivers
5" Kevlar woofers, 3/4" silk dome tweeters
SNR
>95dB (typical A-weighted)
THD+N
<0.05% at all power settings
Crosstalk
-50dB
Frequency response
50Hz-22kHz ±1.5dB
Input impedance
10K ohms unbalanced
Protection
Output current limiting, thermal over-temperature, power on/off transient protection, replaceable external main fuse
Dimensions (each speaker HWD)
Left - 10.75" (27cm) x 7" (18cm) x 9" (23cm)
Right - 10.75" (27cm) x 7" (18cm) x 7.75" (20cm)
Weight (LEFT speaker)
15.4 lbs (7 kg)
Weight (RIGHT speaker)
9.6 lbs (4.4 kg)
Shipping weight
31 lbs (14 kg)
Shipping box dims
15" (38cm) x 22" (56cm) x 11.5" (29cm)
Finish options
Satin Black
Hi-Gloss White
13mm thick MDF cabinets
3/4" silk dome tweeters with neodymium magnets
5" Kevlar woofers with advanced voice coils
Torroidal power transformer
D1 24-bit DAC
DAC type
Dual Mode USB and Optical (SPDIF)
Inputs
USB/Optical (SPDIF)
Outputs
RCA stereo/3.5mm headphone
D/A converter
AKM4396
Optical receiver
CS8416
USB controller
TI1020B
USB device class
Type 1.1 or above
Full-scale output
2.0V RMS
Output impedance
10 ohms
Power source
USB 5V
Power requirements
5V DC, 200mA
USB power filtering
2-stage redundant regulation
SNR
(DC to 20 kHz) >110dB
THD+N
(1kHz FS 96kS/s) <0.0025%
Crosstalkb
-85db
USB transfer mode
Asynchronous (dual clock)
Frequency response
10Hz - 25KHz (+/- 0.5dB)
Input bit depth
16 bit, 24 bit
Input sample rate (USB)
32kHz-96kHz - native playback
188.2kHz, 192kHz - re-sampled to 96kHz for playback
Input sample rate (optical)
32kHz-192kHz - native playback
Product dimensions
3.5x4x1"
Shipping weight
1.0lbs (0.5kg)
Τιμή 380 Ευρώ. Τηλ.6942980705
