Technical characteristics of the Marantz SR7009:
- 11.2 amplifier compatible 3D and 4K
- 11 channels of discrete amplification:
- 11 x 200W (6ohm, 1kHz, 1% THD, 1ch driven)
- 11 x 165W (6ohm, 1kHz, 0.7% THD, 2ch driven)
- 11 x 125W (8ohm, 20Hz-20kHz, THD 0.08%)
- DTS HD Master, DTS 5.1, DTS ES, DTS 96/24, Dolby Digital Plus, Dolby TrueHD, Dolby Digital EX, Dolby Pro Logic IIz, All Stereo, Auddysey DSX, DTS-NEO-X 11.2, and future 3D audio codecs
- MDAX2: improving lossy compressed audio streams
- 8 HDMI 2.0 and HDMI 2.0 inputs 3: ARC, Zone 2, 3D, Deep Color, xvColor, 1080/24p, CEC, & 4K Quad HD Passthrough (2160p/60 4:4:4 and 10-bit, or 2160p / 24 and 12 bit 4:4:4)
- Pure Color: UHD 12-bit 4:4:4 and 24p (4:4:4 10-bit and 60 im / s)
- Sources 3/3 areas: ability to stream different connected via HDMI HDMI HDMI out + Zone 2 sources
- Compatible Remote Marantz bus
- Audyssey MultEQ XT32 (Audyssey Pro compatible), Dynamic Volume, Dynamic EQ, and CFL Pro
- New micro more accurate calibration
- HDMI Standby Pass through consistent 4K/60
- Video processor V8003 Analog Device AD: 1080p upscaling & Ultra HD 2160p/60, post-video processing customizable ISF Certification &
- Build quality and audio revised upwards
- High precision clock master, shocks and shield against interference
- 3 32-bit DSP, DAC 192/24, HDAM modules, circuit against current feedback
- Linear power supply with toroidal transformer and MOSFET transistor
- DLNA, AirPlay, Windows 7 and 8, UPnP
- With graphic OSD Setup Wizard HDMI output 1
- Management of DSD
- USB & UPnP: 192 khz FLAC, DSD128, AIFF, WAV 96 kHz, WMA, MP3, AAC, ALAC and Gapless playback
- DLNA 1.5: Network Streaming, Automatic Update, vTuner Internet Radio, Flickr, Spotify
- Made for iPad / iPod / iPhone: Direct connection via USB, Denon Remote App
- IP / RS232 control Control / network / app control Control
- Pure Audio Mode, and Direct MDAX2
- Wi-Fi and integrated Bluetooth (2 antennas to the rear): codec aptX
- 7.1 analog input and output PREOUT 13.2
- Optimization bass for the front speakers if used without subwoofer
- Front with two buttons (source volume)
- Consumption: 710W
- Programmable remote control with backlit digital display
Technical characteristics of the Marantz SR5009:
- Amplifier 7.2 compliant 3D and 4K
- RMS power advertised:
- 180W (6ohm, 1kHz, 1% THD, 1ch driven)
- 140W (6ohm, 1kHz, 0.7% THD, 2ch driven)
- 100W (8ohm, 20Hz-20kHz, THD 0.08%, 2ch driven)
- DTS HD Master, DTS 5.1, DTS ES, DTS 96/24, Dolby Digital Plus, Dolby TrueHD, Dolby Digital EX, Dolby Pro Logic IIz, All Stereo
- MDAX2: improving lossy compressed audio streams
- 8 HDMI 2.0 inputs and 2 outputs: ARC, 3D, Deep Color, xvColor, 1080/24p, CEC, & 4K Quad HD Passthrough (2160p/60 4:4:4 and 10-bit, or in 2160p/24 4:4 4 and 12 bits)
- Compatible Remote Marantz bus
- Audyssey MultEQ XT, Dynamic Volume, Dynamic EQ
- HDMI Standby Pass through consistent 4K/60
- Video processor V8003 Analog Device AD: 1080p upscaling & Ultra HD 2160p/30, post-video processing customizable ISF Certification &
- DAC 192/24, HDAM modules, circuit against current feedback
- DLNA, AirPlay, Windows 7 and 8, UPnP
- Graphical OSD and 3D color with setup wizard
- Management of DSD (but PCM conversion)
- USB & UPnP: 192 khz FLAC, DSD128, AIFF, WAV 96 kHz, WMA, MP3, AAC, ALAC and Gapless playback
- DLNA 1.5: Network Streaming, Automatic Update, vTuner Internet Radio, Flickr, Spotify Connect
- Made for iPad / iPod / iPhone: Direct connection via USB, Application Marantz Remote App
- IP / RS232 control Control / network / app control Control
- Pure Audio Mode, Audio Restorer, Direct
- Wi-Fi and integrated Bluetooth (2 antennas at the rear)
- 7.1 analog input and output PREOUT 7.2
- Optimization bass for the front speakers if used without subwoofer
- Front with two buttons (source volume)
- Consumption: 650W
