6moons.comThe Ypsilon BC1 transformers are used for converting an unbalanced signal to balanced for use with any kind of unbalanced source like CD players, phono preamps, line preamps etc. They can also be used for breaking ground loops in a system, lowering the total noise floor and improving the interface between equipment by providing galvanic isolation.
Each BC1 has two inputs, one RCA Nextgen connector and one female XLR Neutrik connector and a Cobalt based amorphous core material of very high permeability shielded with mu metal and potted in 10mm soft iron with a nickel coating. Outside magnetic field interference is kept to a minimum. US retail price is $3,600 pair.
The MC transformers were developed in conjunction with the Ypsilon VPS100 phono preamp. They can be used with most moving coil cartridges. The MC10 provides 20db of gain, the MC16 24db and the MC20 26db. When terminated in 47k, the equivalent input impedance is 500, 200 and 140 ohm respectively. If additional loading is needed, it can be done through the parallel input RCA connectors.
The MC series transformers are large-size single C-core double coil transformers using a proprietary amorphous core material shielded with mu-metal and potted in 10mm thick soft iron nickel coated enclosures for immunity to outside magnetic fields and quiet and noise free performance. US retail price is $2,700 each.
